Availability: In stock
SKU: 5000 630
Manufacturer: HES


Your Price:
Warehouse KY DC
Available 7 36
Order
5000 630

Manufactruer: HES

Series: HES 5000 Series Electric Strike
Grade: 1
Frame Application: Wood or Metal
Handing: Non-handed
Faceplates: No
Electrical: .24 Amps 12 VDC/VAC or .12 Amos VDC/VAC. DC-continuous duty/AC-intermittent duty only
Fail Secure/Safe: Field selectable
Finish:  Satin Stainless Steel (630)
Compatible:  Cylindrical locksets
Static Strength: 1,500 lbs
Dynamic Strength: 70 ft-lbs

The 5000 series is a compact, high performance electric strike designed for low profile openings where there is limited space behind the jamb. Its strength is derived from a unique keeper pin locking design, enabling the 5000 to exceed the ratings of the frame, door and locking hardware. This field selectable fail secure/fail safe unit is easy to install and accommodates latchbolts up to 5/8" throw.

Standard Features
•Tamper resistant
•Accommodates 1/2" - 5/8" latchbolt (5/8" with 1/8" door gap)
Strike body depth 1-1/16"
•Dual voltage 12 or 24 VDC/VAC
•Endurance 500,000 cycles
•Internally mounted solenoid
•Non-Handed
•5-year Limited Warranty
•Field selectable fail secure/fail safe
•Plug-In Connector



5000 630

Manufactruer: HES

Series: HES 5000 Series Electric Strike
Grade: 1
Frame Application: Wood or Metal
Handing: Non-handed
Faceplates: No
Electrical: .24 Amps 12 VDC/VAC or .12 Amos VDC/VAC. DC-continuous duty/AC-intermittent duty only
Fail Secure/Safe: Field selectable
Finish:  Satin Stainless Steel (630)
Compatible:  Cylindrical locksets
Static Strength: 1,500 lbs
Dynamic Strength: 70 ft-lbs

The 5000 series is a compact, high performance electric strike designed for low profile openings where there is limited space behind the jamb. Its strength is derived from a unique keeper pin locking design, enabling the 5000 to exceed the ratings of the frame, door and locking hardware. This field selectable fail secure/fail safe unit is easy to install and accommodates latchbolts up to 5/8" throw.

Standard Features
•Tamper resistant
•Accommodates 1/2" - 5/8" latchbolt (5/8" with 1/8" door gap)
Strike body depth 1-1/16"
•Dual voltage 12 or 24 VDC/VAC
•Endurance 500,000 cycles
•Internally mounted solenoid
•Non-Handed
•5-year Limited Warranty
•Field selectable fail secure/fail safe
•Plug-In Connector



Products specifications
Product Type Electric Strike
Finish Satin Stainless Steel (630, US32D)
Series 5000
Grade Grade 1
